Windbreaks may sound like a counterintuitive idea for boosting the performance of a wind turbine. But physicists report that low walls that block wind could actually help wind farms produce more power.
Scientists already knew that the output of a single wind turbine could be improved with a windbreak. While windbreaks slow wind speed close to the ground, above the height of the windbreak, wind speeds actually increase as air rushes over the top. But for large wind farms, there’s a drawback. A windbreak’s wake slows the flow of air as it travels farther through the rows of turbines. That could suggest that windbreaks would be a wash for wind farms with many turbines.
But by striking a balance between these competing effects, windbreaks placed in front of each turbine can increase power output, new computer simulations suggest. It comes down to the windbreaks’ dimensions. Squat, wide barriers are the way to go, according to a simulated wind farm with six rows of turbines. To optimize performance, windbreaks should be a tenth the height of the turbine and at least five times the width of the blades, physicists report July 30 in Physical Review Fluids. Such an arrangement could increase the total power by about 10 percent, the researchers found. That’s the equivalent of adding an additional turbine, on average, for every 10 in a wind farm.
In the simulations, the wind always came from the same direction, suggesting the technique might be useful in locations where wind tends to blow one way, such as coastal regions. Future studies could investigate how this technique might apply in places where wind direction varies.
